Custom platform sizes are available. Contact us for details.
The platform frame is constructed with a versatile T-slotted framing rail made from 6105-T5 aluminum alloy. The long sides are made with 2 x 1 solid double T-slot and the short sides use 1 x 1 solid T-slotted beams.
| Model: | Attic-Lift 1400 |
| Lifting Capacity: | Up to 400 lbs |
| Max. Travel Distance1: | 12 ft or 18 ft |
| Installation Guide: | Attic-Lift Installation Guide (PDF) |
| Owner Manual: | Attic-Lift Owners Manual (PDF) |
| Owner Manual: | Attic-Lift Bottom Cover Installation Guide (PDF) |
| Frame: | T-slotted framing rail |
| Material: | 6105-T5 aluminum alloy |
| Decking: | 3/4 in thick Oak veenered plywood (5-ply) |
| Cable: | 1/8” Vinyl-coated Steel 7x19 |
| Cable Strength3: | 2,000 lbs |
| Type: | (2) 1 5/8" x 60" strut channel |
| Fasteners: | (8) 5/16" x 4" SPAX© Lag Bolts |
| Rated Power: | 235 W |
| Rated Current: | 2.2 A |
| Type: | IP44 (T-Motor) |
| Voltage / Phase: | 100-120V AC / Single |
| Duty Cycle @ Max. Capacity: | 3 min on, 15 min off3 |
| Switch Voltage: | 110V / 120V |
| Transmitter: | 433.92 MHz |
| Electrical Cord: | 10 FT / 16 gauge / NEMA 5-15 |
| Min. circuit size: | 15 amp |
| Platform Size (Small): | 20.75 in x 44 in |
| Ceiling Cutout Size: | 22.5 in x 46.5 in |
| Platform Size (Large): | 28.75 in x 56 in |
| Ceiling Cutout Size: | 30.5 in x 58.5 in |
|
Name |
Part # |
Qty |
| Controller | 1107A | 1 ea |
| Remote control | 1105A | 1 ea |
| ZSB motor left (400lbs) | 1509A | 1 ea |
| ZSB motor right (400lbs) | 1512A | 1 ea |
| 1-1/8in x 1/8in screws (For controller) | 0509A | 4 ea |
| Expansion anchors (for controller) | 0803A | 4 ea |
| Strut covers | 1206A | 2 ea |
| Rail cover caps | 1207A | 4 ea |
| Washers (for lag bolts) | 0400A | 8 ea |
| Lag bolts w/hex-head - 5/16in x 3in | 0507A | 8 ea |
| M12x24 bolt (for motor seating bracket) | 0505A | 4 ea |
| Washers (for motor seating bracket) | 0400A | 4 ea |
| Rubber PG grommets | 0802A | 2 ea |
| Strut spring nuts - 1/2in | 0302A | 4 ea |
| Motor seating bracket | 0201C | 4 ea |
| 60in strut channel (no side holes) | 1205A | 1 ea |
| 60in strut channel (w/ side holes) | 1213A | 1 ea |
| Cotter pins | 0602A | 4 ea |
| Wire rope clips w/ 2ea nuts | 0703A | 4 ea |
| Spring-loaded damper bracket (L) | 1505A | 2 ea |
| Spring-loaded damper bracket (R) | 1506A | 2 ea |
| 3ft long allen key extension stick w/ handle | 0002A | 2 ea |
| Warning label stickers | 2001A | 1 ea |
| 10ft power cable (white) | 1071B | 1 ea |
| Platform material | 1000A | 1 ea |
1 Standard cable allows up to 12 ft of travel. Extended length option allows up to 18 ft of travel.
2 Ultimate tensile strength
3 If you run the Attic-Lift continuously for more than three minutes at a time (approximately two round-trips), the motors will switch off automatically and require a cool-down period of 15 minutes or less.
Custom platform sizes are available. Contact us for details.
The platform frame is constructed with a versatile T-slotted framing rail made from 6105-T5 aluminum alloy. The long sides are made with 2 x 1 solid double T-slot and the short sides use 1 x 1 solid T-slotted beams.
| Model: | Attic-Lift 1400 |
| Lifting Capacity: | Up to 400 lbs |
| Max. Travel Distance1: | 12 ft or 18 ft |
| Installation Guide: | Attic-Lift Installation Guide (PDF) |
| Owner Manual: | Attic-Lift Owners Manual (PDF) |
| Owner Manual: | Attic-Lift Bottom Cover Installation Guide (PDF) |
| Frame: | T-slotted framing rail |
| Material: | 6105-T5 aluminum alloy |
| Decking: | 3/4 in thick Oak veenered plywood (5-ply) |
| Cable: | 1/8” Vinyl-coated Steel 7x19 |
| Cable Strength3: | 2,000 lbs |
| Type: | (2) 1 5/8" x 60" strut channel |
| Fasteners: | (8) 5/16" x 4" SPAX© Lag Bolts |
| Rated Power: | 235 W |
| Rated Current: | 2.2 A |
| Type: | IP44 (T-Motor) |
| Voltage / Phase: | 100-120V AC / Single |
| Duty Cycle @ Max. Capacity: | 3 min on, 15 min off3 |
| Switch Voltage: | 110V / 120V |
| Transmitter: | 433.92 MHz |
| Electrical Cord: | 10 FT / 16 gauge / NEMA 5-15 |
| Min. circuit size: | 15 amp |
| Platform Size (Small): | 20.75 in x 44 in |
| Ceiling Cutout Size: | 22.5 in x 46.5 in |
| Platform Size (Large): | 28.75 in x 56 in |
| Ceiling Cutout Size: | 30.5 in x 58.5 in |
|
Name |
Part # |
Qty |
| Controller | 1107A | 1 ea |
| Remote control | 1105A | 1 ea |
| ZSB motor left (400lbs) | 1509A | 1 ea |
| ZSB motor right (400lbs) | 1512A | 1 ea |
| 1-1/8in x 1/8in screws (For controller) | 0509A | 4 ea |
| Expansion anchors (for controller) | 0803A | 4 ea |
| Strut covers | 1206A | 2 ea |
| Rail cover caps | 1207A | 4 ea |
| Washers (for lag bolts) | 0400A | 8 ea |
| Lag bolts w/hex-head - 5/16in x 3in | 0507A | 8 ea |
| M12x24 bolt (for motor seating bracket) | 0505A | 4 ea |
| Washers (for motor seating bracket) | 0400A | 4 ea |
| Rubber PG grommets | 0802A | 2 ea |
| Strut spring nuts - 1/2in | 0302A | 4 ea |
| Motor seating bracket | 0201C | 4 ea |
| 60in strut channel (no side holes) | 1205A | 1 ea |
| 60in strut channel (w/ side holes) | 1213A | 1 ea |
| Cotter pins | 0602A | 4 ea |
| Wire rope clips w/ 2ea nuts | 0703A | 4 ea |
| Spring-loaded damper bracket (L) | 1505A | 2 ea |
| Spring-loaded damper bracket (R) | 1506A | 2 ea |
| 3ft long allen key extension stick w/ handle | 0002A | 2 ea |
| Warning label stickers | 2001A | 1 ea |
| 10ft power cable (white) | 1071B | 1 ea |
| Platform material | 1000A | 1 ea |
1 Standard cable allows up to 12 ft of travel. Extended length option allows up to 18 ft of travel.
2 Ultimate tensile strength
3 If you run the Attic-Lift continuously for more than three minutes at a time (approximately two round-trips), the motors will switch off automatically and require a cool-down period of 15 minutes or less.
(For General Reference Only)
Price Match Guarantee: We'll beat any price
No Sales Tax outside New York
30-Day Easy Returns
Free Design Service
Authorized Dealer for all top brands
Superhuman Customer Service
100% Quality Assured
▶ Click Here ◀ for a Complete List of Reasons Why Inventive Is Your Best Choice
▶ Click Here◀ for Complete Shipping Details
Finally! Use ALL of Your Storage Space!
Elevate your home storage game with the Attic-Lift from Auxx-Lift, the smart solution designed to maximize your attic space above the garage. This motorized lifting platform eliminates the need to carry items up hazardous pull-down stairways, allowing you to safely and effortlessly store items weighing up to 400 lbs. With its wireless remote control, programmable stopping points, and self-leveling platform, the Attic-Lift prioritizes your convenience and safety. Custom platform sizes ensure a perfect fit for your attic opening, while the easy installation process means you'll be enjoying the benefits of a more organized home in no time. Upgrade to the Attic-Lift and experience the difference in your storage strategy today.
Installation is a breeze; simply attach two motors and two struts directly to your attic floor, without the hassle of obstructing posts or rails like you'd find with old-school attic elevator competitors. The innovative design includes a frame to perfectly seal your ceiling opening, fully adjustable to fit all attic floor framing dimensions.
Choose from two platform sizes to match your needs, ensuring a snug fit for your attic opening. Forget attic stairs or cumbersome access methods; with our lift, use a ladder to reach your attic, then effortlessly elevate your items using the lift, streamlining the unloading process directly onto the attic floor. (Custom sizes available with a small upcharge.)
Upgrade your home storage strategy with our attic lift and elevate your organizational efficiency to new heights!
3/4" Thick 5-Ply Oak Veneered Plywood Platform Included
No Heavy Lifting: The lift can safely handle up to 400 lbs, eliminating the safety hazard of carrying heavy items up and down steep pull-down stairways.
Wireless Remote-Control: Equipped with an easy-to-use remote control, allowing you to safely lower and raise your items.
Programmable Stopping Points: This feature allows you to set high and low point parameters, preventing your items from hitting the floor.
Safety Features: The lift comes with a variety of safety features, including a self-leveling platform and a stop limit to prevent overloading.
Custom Platform Sizes: In addition to standard sizes, custom platform sizes are available to meet specific storage needs.
Easy Installation: The Attic-Lift is designed to be easy to install, with all the necessary hardware included.
Auxx-Lift's Attic-Lift is a versatile and safe solution for maximizing storage space in your home, offering convenience and safety, even when storing your heaviest and bulkiest items in the attic.
Auxx-Lift is dedicated to enhancing home storage with their innovative overhead storage solutions, proudly made in the USA. Assembling all models in Moorpark, California, they combine American craftsmanship with globally sourced materials.
Custom platform sizes are available. Contact us for details.
The platform frame is constructed with a versatile T-slotted framing rail made from 6105-T5 aluminum alloy. The long sides are made with 2 x 1 solid double T-slot and the short sides use 1 x 1 solid T-slotted beams.
Material: 6105-T5 Aluminum Finish: Anodized Silver Tensile Strength: 35,000 psi| Model: | Attic-Lift 1400 |
| Lifting Capacity: | Up to 400 lbs |
| Max. Travel Distance1: | 12 ft or 18 ft |
| Installation Guide: | Attic-Lift Installation Guide (PDF) |
| Owner Manual: | Attic-Lift Owners Manual (PDF) |
| Owner Manual: | Attic-Lift Bottom Cover Installation Guide (PDF) |
| Frame: | T-slotted framing rail |
| Material: | 6105-T5 aluminum alloy |
| Decking: | 3/4 in thick Oak veenered plywood (5-ply) |
| Cable: | 1/8” Vinyl-coated Steel 7x19 |
| Cable Strength3: | 2,000 lbs |
| Type: | (2) 1 5/8" x 60" strut channel |
| Fasteners: | (8) 5/16" x 4" SPAX© Lag Bolts |
| Rated Power: | 235 W |
| Rated Current: | 2.2 A |
| Type: | IP44 (T-Motor) |
| Voltage / Phase: | 100-120V AC / Single |
| Duty Cycle @ Max. Capacity: | 3 min on, 15 min off3 |
| Switch Voltage: | 110V / 120V |
| Transmitter: | 433.92 MHz |
| Electrical Cord: | 10 FT / 16 gauge / NEMA 5-15 |
| Min. circuit size: | 15 amp |
| Platform Size (Small): | 20.75 in x 44 in |
| Ceiling Cutout Size: | 22.5 in x 46.5 in |
| Platform Size (Large): | 28.75 in x 56 in |
| Ceiling Cutout Size: | 30.5 in x 58.5 in |
|
Name |
Part # |
Qty |
| Controller | 1107A | 1 ea |
| Remote control | 1105A | 1 ea |
| ZSB motor left (400lbs) | 1509A | 1 ea |
| ZSB motor right (400lbs) | 1512A | 1 ea |
| 1-1/8in x 1/8in screws (For controller) | 0509A | 4 ea |
| Expansion anchors (for controller) | 0803A | 4 ea |
| Strut covers | 1206A | 2 ea |
| Rail cover caps | 1207A | 4 ea |
| Washers (for lag bolts) | 0400A | 8 ea |
| Lag bolts w/hex-head - 5/16in x 3in | 0507A | 8 ea |
| M12x24 bolt (for motor seating bracket) | 0505A | 4 ea |
| Washers (for motor seating bracket) | 0400A | 4 ea |
| Rubber PG grommets | 0802A | 2 ea |
| Strut spring nuts - 1/2in | 0302A | 4 ea |
| Motor seating bracket | 0201C | 4 ea |
| 60in strut channel (no side holes) | 1205A | 1 ea |
| 60in strut channel (w/ side holes) | 1213A | 1 ea |
| Cotter pins | 0602A | 4 ea |
| Wire rope clips w/ 2ea nuts | 0703A | 4 ea |
| Spring-loaded damper bracket (L) | 1505A | 2 ea |
| Spring-loaded damper bracket (R) | 1506A | 2 ea |
| 3ft long allen key extension stick w/ handle | 0002A | 2 ea |
| Warning label stickers | 2001A | 1 ea |
| 10ft power cable (white) | 1071B | 1 ea |
| Platform material | 1000A | 1 ea |
1 Standard cable allows up to 12 ft of travel. Extended length option allows up to 18 ft of travel.
2 Ultimate tensile strength
3 If you run the Attic-Lift continuously for more than three minutes at a time (approximately two round-trips), the motors will switch off automatically and require a cool-down period of 15 minutes or less.
Inventive Garage & Workshop offers professional installation services in most areas of the country. Please contact us at 800-948-7780 for more details or to schedule an installation of your ceiling-mounted storage system.
Installing the Auxx-Lift Attic-Lift is an easy DIY project if you're handy. It gets installed into a framed opening in the ceiling, similar to the opening for a pull-down attic ladder.
Please ensure your home framing is robust enough to support the maximum weight you intend to place on the elevator platform. This is especially important with a truss roof structure. Responsibility rests entirely with the installer.
