| Specification | Details |
|---|---|
| Glazing Type | Tempered-over-laminated Low-E, argon-filled, double-glazed |
| Warm-Edge Spacer | TGI |
| U-Factor (whole skylight): | 0.39 BTU/h·ft²·°F |
| Glazing-Only U-Value: | 0.19 BTU/h·ft²·°F |
| Solar Heat Gain Coefficient (SHGC): | 0.21 |
| Visible Transmittance (VT): | 0.39 |
| Air Leakage: |
0.025 cfm/ft² @ 1.57 psf (tested size 24×70) |
| Condensation Resistance: | 60 |
| Water Penetration Resistance: | 730 Pa |
| UV Blocked: | up to 99.8% |
| Energy Rating: | ENERGY STAR certified |
| Frame Material: | Hand-selected, pressure-treated pine |
| Frame Finish: | White, double-coated acrylic lacquer |
| Weathersealing: | Perimeter gasket + internal drainage channels |
| Roof Pitch Range: | 15°–85° (3/12–137/12) |
| Max Install Elevation (Standard Glazing): | 3,000 ft above sea level |
| Flashing (required for warranty): | EL low-profile (shingle, slate, low-profile tile); EH high-profile tile or standing-seam metal |
| Unit Weight Range: | 34–96 lbs |
| Leak-Proof Warranty: | 10 years — with matched FAKRO flashing + ice-and-water shield, installed per instructions |
| Materials / Workmanship Warranty: | 10 years |
| Insulating Glass Seal Warranty: | 10 years |
| Laminated-Glass Hail Warranty: | 20 years (golf-ball-size hail or smaller) |
Every FX "R" size uses the same rough opening as a VELUX deck-mounted skylight, so it fits an existing VELUX opening without reframing. Match your old unit's size code below.
| FAKRO model | Rough opening | Same opening as VELUX size |
|---|---|---|
| FX 106R | 14 1/2 x 45 3/4 in. | A06 |
| FX 301R | 21 x 26 7/8 in. | C01 |
| FX 304R | 21 x 37 7/8 in. | C04 |
| FX 306R | 21 x 45 3/4 in. | C06 |
| FX 308R | 21 x 54 7/16 in. | C08 |
| FX 312R | 21 x 70 1/4 in. | C12 |
| FX 504R | 30 1/16 x 37 7/8 in. | M04 |
| FX 506R | 30 1/16 x 45 3/4 in. | M06 |
| FX 508R | 30 1/16 x 54 7/16 in. | M08 |
| FX 801R | 44 1/4 x 26 7/8 in. | S01 |
| FX 806R | 44 1/4 x 45 3/4 in. | S06 |
Roof Installation With EL Flashing
Roof Installation With EH-A Flashing

FAKRO has grown into a global leader in roof window manufacturing, holding approximately 15% of the worldwide market share. The company offers a diverse product range, including roof windows, skylights, attic ladders, and related accessories. With a dedicated R&D team of over 100 engineers, FAKRO focuses on innovation and holds numerous patents to improve home comfort and energy efficiency.
10-year FAKRO limited warranty: 10 years on materials and workmanship, 10 years on the insulating glass seal, and 20 years against hail breakage of the laminated glass pane. Installed with the original FAKRO flashing kit and ice-and-water shield to FAKRO's instructions, the skylight also carries FAKRO's 10-year leak-proof installation warranty.
